Uovision UM785-4G LTE Cloud 20MP Full HD Trail Camera
Temporarily out of stock
With part payment / month starting at: 15,83 €
Temporarily out of stock. Submit your email and we'll notify you when this product becomes available.
Product info
Equipped with 20MP resolution for still images, the Uovision UM785-4G LTE Cloud 20MP Full HD is a digital sending and remote trail camera that supports the free LinckEazi cloud service! The free LinckEazi cloud service is a true surveillance command center from which you control one or more Uovision cameras. High-speed LTE 4G connection ensures high-quality image transmission quickly from the destination!Norwegian Test Winner: The test winner chosen by the Norwegian Hunters and Fishermen's Association (Norges Jeger- og Fiskerforbund) 8/2020 is the Uovision UM785-4G LTE trail camera! Modern LTE 4G technology transfers image and video faster than before. LTE 4G technology transfers material up to half the speed of similar 3G devices. Speed is an advantage, especially when high-quality footage is needed from the target immediately, eg for surveillance use. Uovision UM785-4G LTE sends high-definition images or videos to the free LinckEazi cloud service and, if necessary, to the user's own e-mail. You can choose from the LinckEazi cloud service yourself, whether you want the images coming from the camera to the cloud service or to your e-mail or both!
FREE LINCKEAZI CLOUD SERVICE - A REAL CONTROL COMMAND CENTER!
With the free LinckEazi cloud service, the Uovision UM785-4G LTE game camera can be remotely controlled using your own computer or the free LinckEazi APP (Android, iOS) application. The LinckEazi cloud service enables control of several cameras where images and videos are stored in the cloud service in the user's own account in camera-specific albums. From the albums, you can easily browse the day's events from different cameras and, if necessary, change the camera settings remotely free of charge from the LinckEazi cloud service.
You can also instruct the camera to take a picture or video and see them all from your own “central control room” - the LinckEazi cloud. LinckEazi WebPortal software APPs can be downloaded from the Google Play (Android phone) or App Store (iOS phone) store with the keyword LinckEazi. With the free WebPortal software APPs, you get a monitored and managed game camera free of charge, even without a home computer!
With the LinckEazi cloud service, you also save the price of remote text messages compared to a traditional remote-controlled game camera. You can use the LinckEazi cloud service on your own computer via a web browser and / or on your own mobile phone via the Web Portal. Language options can be found in the language menu of the LinckEazi cloud service; Finland, Sweden, Norway, England and Germany. From the LinckEazi cloud service, you can also see the most important information about the camera status, eg battery charge, SD memory card status, cloud service memory status, etc.
EASY CAMERA INSTALLATION WITH LINCKEAZI CLOUD SERVICE
Deploying the LinckEazi cloud service is extremely easy. After creating a free user account, you add the camera to the service by entering the device serial number and IMEI code. If the camera has a working internet connection that supports 4G LTE connection (speed at least 100MB / s), the camera will be connected directly to your account. After that, shooting can start right away!
The Uovision UM785-4G LTE camera automatically logs on to the operator's network without complicated installations!
VERSATILE USE
The Uovision UM785-4G LTE game camera starts automatically due to human or animal heat movement. It has a passive PIR motion detector that detects a radiant object in front of the camera. The remote-controlled game camera is suitable as a game camera for off-road photography of four-legged or winged nature movers. It can be installed as a surveillance camera to monitor two-legged unauthorized guests in a cottage, construction site, home or office, for example. The remote-controlled transmitting camera always keeps you up to date, wherever you are!
Uovision UM785-4G LTE Cloud, which sends fast and high-quality material, is a great choice for a summer cottage or a solution with which wireless camera surveillance is possible at home. The price of a trail camera is much cheaper than camera surveillance or other fixed installation solutions. The camera surveillance sticker must be remembered when recording videos.
The camera automatically records high-definition still images or video clips and sends them to the LinckEazi cloud service. The camera transmits Full HD and HD videos in 10sec length and WVGA videos in 20sec length. During the day, images and videos are recorded in color, at night in black and white thanks to the infrared flash. The camera is intended for year-round outdoor and indoor use. The original footage is always stored on the SD Memory Card in the camera.
Recordings (image or video) are sent by the camera to the LinckEazi cloud service via a high-speed 4G wireless connection. For transmission, a SIM card that supports LTE 4G connection must be obtained from the operator. The commercially reported subscription speed must be at least 100MB / sec. The camera supports frequencies: FDD-LTE B1 / B3 / B5 / B7 / B8 / B20, TDD-LTE: B38 / B40 / B41, WCDMA: B1 / B5 / B8; GSM: 900/1800
When the camera logs on to the network, it automatically retrieves the date and time from the network.
OPERATION MENU
The menu menu of the easy-to-use Uovision UM785-4G LTE game camera and cloud service is in Finnish and Swedish. In addition, 8 other EU languages ??(Danish, Norwegian, English, German, French, Italian, Hungarian, Czech). Easy-to-understand picture icons help you progress through a clear menu. The camera comes with clear operating instructions in Finnish, which allow you to adjust the camera's various settings to your liking.
Versatile settings can be changed remotely at any time using the LinckEazi cloud service. The LinckEazi cloud service allows you to set the correct time zone for the camera as well as subscribe to useful automatic alerts such as a temperature alarm or low battery alarm. You can easily send the camera because all the SSL-secured transmission settings of the most common operators are pre-programmed into the camera's intelligence! All you have to do is insert the SIM card into the camera. When the camera logs on to the network, it automatically retrieves the date and time from the network.
TRANSMISSION OF IMAGES AND VIDEOS
To send images or videos, the camera must have an Internet connection that supports 4G LTE (at least 100MB / sec). With a subscription with a fixed-price online package, the camera can send material indefinitely for a fixed monthly fee. Incoming photos or videos go to the LinckEazi cloud service and a copy to your own email or both!
Uovision UM785-4G LTE sends images and videos SSL-protected, for example, via the Internet subscriptions of the following operators without a separate additional service: Telia, Elisa, Saunalahti, Saunalahti Pre-Paid, DNA and DNA Pre-Paid.
REMOTE CONTROL
The Uovision UM785-4G LTE game camera is equipped with versatile remote control features. The LinckEazi cloud service enables the exchange of settings remotely on a mobile phone using software APPs or on a computer Web portal from the LinckEazi cloud service. Remote control commands made remotely via the cloud service are free of charge!
The most common remote commands are, for example, picture or video request, PIR motion sensor delay adjustment, shooting mode change (still picture vs video). The camera can be programmed With the help of the work schedule, it can be programmed to take pictures only at a certain time on a certain day of the week or even completely deactivated or activated when you are at the cottage, for example. All remote commands of the camera can be sent via the LinckEazi Web Portal cloud service and via mobile phone using the APPs application, free of charge!
20MP IMAGE RESOLUTION WITH FULL HD VIDEO AND SOUND
The Uovision UM785-4G LTE is equipped with a sharp 20MP high resolution description. Pictures and videos can be viewed on the camera from your 2.4? from the color screen. Sounds are also recorded on Full HD (1080P) or HD (720P) and WVGA level videos recorded by the camera! Sounds are very useful for surveillance use. The camera sends 1080P Full HD videos as well as 720P HD videos in 5 to 10 sec lengths and WVGA videos in 5-20 sec lengths to its owner's LinckEazi cloud service.
From the LinckEazi cloud service, you can see the material sent by the camera (pictures / videos) so you can view them anytime, anywhere, either on your mobile phone or computer! Video in mp4 format supports video playback on almost all smartphones, so no separate decoder is required to watch the video on your smartphone's screen. Optional video lengths are selectable from 5 sec to 60 sec. The camera transmits max 20sec video (WVGA) and the excess is stored on the SD memory card.
TRANSMISSION OF IMAGES AND VIDEOS
To send images or videos, the camera must have a 4G LTE connection that supports a 4G LTE connection (at least 100MB / sec). With a subscription with a fixed-price online package, the camera can send material indefinitely for a fixed monthly fee. Incoming images or videos go to the LinckEazi cloud service and, if necessary, as a copy to your own email. Uovision UM785-4G LTE Cloud sends images and videos SSL-protected, for example, via the Internet subscriptions of the following operators without a separate additional service: Telia, Elisa, Saunalahti, Saunalahti Pre-Paid, DNA and DNA Pre-Paid.
0.6sec PIR MOTION SENSOR TRIP RESPONSE
The Uovision UM785-4G LTE game camera captures subjects with a fast 0.6sec shutter response. A quick shutter response is necessary when the subject is moving. This function is especially good when the camera is used for surveillance tasks, enabling sharp and clear images of the subject quickly. The sensitivity of the motion sensor can be adjusted in the following levels: High, Automatic and Low. The range of the PIR motion sensor perpendicular to the camera is about 16 meters (human subject).
UNIQUE SHUTTER SHUTTER SPEED FUNCTION
The Uovision UM785-4G LTE game camera is equipped with a special shutter speed control function. If necessary, the shutter speed can be changed from the normal setting to fast, depending on what it describes. This function is especially good when the camera is used for surveillance tasks, enabling sharp and clear images quickly.
Take full advantage of Full HD!
The custom setting allows you to fine-tune your own settings where you can choose the resolution for your images; 20MP, 16MP, 12MP, 10MP, 8MP, 3MP. Flash output control: High / Low. Adjustable image pulse rate: 1 to 10 images.
2.4 ”COLOR LCD DISPLAY
The camera's own LCD screen helps when the camera is aimed at terrain. You can see the intended shooting area directly on the camera's own LCD screen before activating the camera. You know for sure in advance what area the camera was left to capture and you don’t have to take time-consuming test shots by walking in front of the camera and waiting for the images to arrive on your mobile phone.
The sharp 2.4 "color screen allows you to use a larger font in the menu menu. The camera's menu uses a larger font than usual, making it easier to read and change the camera's various menu settings. The clear text font is also great in bright weather outdoors!
You can view the original high-resolution photos and videos stored on the SD memory card on-site on the camera's built-in 2.4 ”screen. The programming of the device's functions is easily done on site from the same 2.4 ”color display.
42 LED HIGH POWER INFRAM BLACK 940nm
The Uovision UM785-4G LTE game camera has a 42 LED powerful infrared flash completely invisible to the human eye. A completely invisible flash is an absolute prerequisite if the transmitting Uovision UM785 game camera is also used for surveillance tasks in various locations. The infrared flash automatically turns on at dusk, allowing the game camera to capture black-and-white night photos or videos of the subject. The twilight sensor automatically turns off the flash during the day, when it normally captures subjects as color images or videos.
The flash output can be adjusted from the settings: High / Low output. Lower power is necessary if the camera is shooting in small interiors, for example, and you want to avoid reflections from a white wall. Flash range up to approx. 15m.
SD MEMORY CARD
Images and videos stored on the Uovision UM785-4G LTE are saved on the SD memory card. The device supports standard 2GB to 32GB SD memory cards. The camera supports overwriting, so the camera writes new recordings over the old ones from the oldest end in case the SD memory card is accidentally filled. If necessary, the overwrite can also be switched off.
7 DAY / 4 WEEK WEEKLY SCHEDULE TOOL
The Uovision UM785-4G LTE game camera comes with a weekly tool that allows the camera to be scheduled in advance to shoot at a specific schedule each day of the week. The camera can be programmed for 4 different weeks with different hours of active weekly work schedule program, in which case the camera is active several times at different times of the day, if necessary. This function is good if you want the camera to be active only at night or to close during business hours.
3min - 24h TIME INTERVAL (Time Lapse)
The Uovision UM785-4G LTE game camera can be pre-timed to take pictures at regular intervals as so-called equal time shooting (TimeLapse). Time Lapse allows the camera to preset to take a picture of an area without motion detection by the PIR motion sensor. Equal time shooting can be set between 3min - 55min or 1h - 24h every hour.
This function is good if you want to get an image from the trap automatically once a day, or if the camera is a cottage guard, it can be remotely “switched off” and “switched on” with this function when you are on the spot.
During time-lapse shooting, the PIR motion sensor can optionally also be turned on, in which case it triggers shooting if a subject enters the area. An image taken with interval shooting is identified by an image that is stamped (T-L).
TIME STAMP INFORMATION STORED IN IMAGES
At the bottom of each image, useful timestamp information is stored that shows, for example, time, date, temperature, battery charge status, or the motion sensor entry that triggered the recording. You can conveniently monitor the battery charge status of incoming images without a separate query.
ONLINE LOCATION
The Uovision UM785-4G LTE game camera is also equipped with network positioning. Network positioning works with the prevailing operator's density positioning allowing the camera to locate the LincEazi cloud service on a map when asked for location. The denser the operator's regional network, the more accurate the network positioning.
POWER SUPPLY
The Uovision UM785-4G LTE game camera's own internal battery compartment contains 12 AA alkaline batteries at a time. The camera also supports 6V external power sources such as a battery or AC adapter. If you use an external battery cable or power supply, the front cover of the Uovision camera will open without first having to disconnect the cable to the camera separately!
From the images sent by the camera, you can also quickly see the battery charge status without any request. This feature allows you to easily keep track of when it's time to go to the camera to replace the batteries.
CAMERA BRACKETS
The Uovision UM785-4G LTE has a wide range of mounting options. The included wood fastening strap makes it easy to fasten around the wood frame. Below and behind the camera, there are mounting threads for a possible wall mount. The mounting thread allows for more versatile positioning and tilting of the camera. The game camera lock has a separate locking port on the slide latch and an 8mm Ø groove on the back of the camera.
The convenient weather protection developed by Uovision provides protection against rain and snow. The sturdy Uovision weather protection, specially designed for Finnish weather conditions, protects your camera from all wood and sky dripping.
PASSWORD
All Uovision game cameras have four-digit password protection in case the camera falls into the wrong hands. User manual in Finnish included. Warranty for manufacturing and material defects 12 months (1 year). Product CE, FCC and RoHS approved.
- Super fast image and video transmission with LTE (4G) connection
- Quickly sends high-quality footage
- Easy to set up and ship
- Remote controlled and broadcast LTE (4G) game camera supporting free LinckEazi cloud service
- SSL secured connection for sending images and videos to the LinckEazi cloud service
- If necessary, also send pictures and videos to your own e-mail
- Free remote control commands to change settings using Web Portal or APPs from your mobile phone
- Versatile remote control commands with the free LinckEazi cloud service
- Shooting modes: Still image, Video
- 20MP sharp digital high resolution description
- Resolutions: 20MP / 16MP / 12MP / 10MP / 8MP / 3MP
- Video Resolutions: Full HD 1080P, HD 720P, WVGA
- Video length: 5-60s
- Image pulse: 1 to 10 images
- Trigger response: 0.6s
- Diagonal lens angle: 52 °
- FOV10m (Field of View 10m): 7.34 meters
- Luminance of the object: F1.8
- SD memory card support: 2GB - 32GB (check with vendor for compatibility)
- PIR Motion Detector: Multi Zone PIR up to 16m
- Adjustable PIR Motion Sensor Sensitivity: High / Normal / Low
- PIR delay: 0s - 60 min.
- Equal time description (timelapse): 3min-24h
- Shooting time stamp: day, time, temperature, battery charge
- Programmable 7-day weekly scheduling tool for 4 different weeks (schedule description in active hours)
- Flash High Power LED technology: 42 power LEDs
- Adjustable InfraBlack Flash: 100% / 50% power controls
- Color TFT display: 2.4 ”LCD (image viewing and programming)
- Outputs: USB, 6V DC, SD memory card slot, SIM card slot
- Location of the tripod mounting screw on the bottom and back of the camera
- Password protection
- Network positioning location information, accuracy depends on the density of the operator masts
- Lockable: Lock mounting rings on the shell
- Included: lashing strap, instruction manual, 21cm flat LTE (4G) antenna
- Camo pattern: pictured
- Black 21cm long flat LTE (4G) antenna
- Weight: 495g (without batteries)
- Operating temperature -30 ° C… + 60 ° C
- Operating humidity: 5% - 90%
- Weatherproof construction, IP54 rating (no immersion in liquid)
- Batteries: 12pcs 1.5V AA (not included)
- Dimensions: 140 x 87 x 55mm
- Windows (98, 2000, XP, Vista, Win7, Win8, Win10) compatible
- LTE 4G frequencies: FDD-LTE B1 / B3 / B5 / B7 / B8 / B20, TDD-LTE: B38 / B40 / B41, WCDMA: B1 / B5 / B8; GSM: 900/1800
- 8GB to 32GB SD memory cards
- “Area camera surveillance” stickers
- Weather protection plastic
- Wall bracket
- Metal camera cover
- Game camera lock
- Power cord for external power supply
- Uovision 6V batteries (7.5Ah and 12Ah)
- Uovision 6V battery charger
- Mains power supply 220V (indoor use)
